价格：￥3.20/PCS
品牌：QITDA
接口类型：RJ45水晶头
形状：矩形
起订：1000PCS
供应：2000000PCS
发货：10天内
发送询价
| 接口类型 | RJ45水晶头 |
|---|---|
| 形状 | 矩形 |
| 应用范围 | 电脑 |
| 制作工艺 | 组装 |
| 绝缘体材质 | PBT |
| 接触件材质 | 镀金铜 |
| 品牌 | 祺泰达 |
| 型号 | RJ45F 2*2 |
1. MATERIAL:
HOUSING: LCP WITH 30% UL94V-0, COLOR BLACK.
TERMINAL: PHOSPHOR BRONZE. C5210 T=0.25±0.01mm
SHIELD: BRASS T=0.25±0.01mm
2. FINISH:
CONTACT: GOLD PLATING (SEE TABLE) ON ConTACT AREA
1.27um[50u'']MIN. NICKEL UNDERPLATED OVERALL.
2.54um[100u'']MIN. MATTE-TIN ON SOLDER TAIL.
SHIELD: NICKEL PLATED.
3. LED SPEC:
3.1 DOMINANT WAVELENGTH: GREEN: 566~574NM. YELLOW: 585~594NM.
3.2 DOMINANT WAVELENGTH: AMBER: 600~610NM. WHITE: 200~600NM.
3.3 FORWARD VOLTAGE(IF=20MA): GREEN, 2.6V MAX; YELLOW,2.5V MAX.
3.4 FORWARD VOLTAGE(IF=20MA): AMBER, 2.4V MAX; WHITE,3.6V MAX.
3.5 FORWARD CURRENT:20mA MAX.
