价格：￥0.00/件
品牌：普源
发货：3天内
Rigol MSO5354 Digital Oscilloscope
The MSO5354 is a 350MHz, 4CH high-performance Digital Oscilloscope model design based on RIGOL UltraVision II technology. The MSO5000 series integrates 7 independent instruments into one. The MSO5000 series offers a high sample rate / bandwidth ratio, high memory depth, clear 9 inch touch-screen display, excellent waveform capture rate and powerful data analysis functions. Many of its specifications are industry leading. These instruments are expected to be popular for R&D, univerSITIes, production , quality control, communications engineering, automotive engineering, aerospace engineering, industrial and power markets.
Features:
Analogue bandwidth: 350 MHz; bandwidth upgrade option supported
2 or 4 analogue channels (upgradeable), standard 16 digital channels(LA probe required)
Up to 8 GSa/s real-time sample rate
Up to 200 Mpts memory depth (option)
High waveform capture rate (over 500,000 wfms/s)
Auto measurement of 41 waveform parameters; full-memory hardware measurement function
A variety of serial protocol triggers and decodes
NEW Bode Plot Analysis – Automate advanced device characterisation with new phase and gain analysis capabilities
Up to 450,000 frames of hardware real-time and ceaseless waveforms recording and playback functions
Independent search, navigation keys, and event table
Built-in advanced power analysis software (option)
Integrates 7 independent instruments into 1, including a digital oscilloscope, a logic analyser, a spectrum analyser, an arbitrary waveform generator, a digital voltmeter, a frequency counter and totaliser, and a protocol analyser
9-inch capacitive multi-touch screen, 256-level intensity grading display, with colour persistence
Multiple interfaces available: USB HOST&DEVICE, LAN(LXI), HDMI, TRIG OUT, and USB-GPIB
Web Control remote command
Unique online version upgrade
Novel and delicate industrial design, easy to operate
Supplied with… 4-off passive probes (500MHz), USB cable, UK & European mains leads, quick guide
Rigol MSO5000 Oscilloscope Comparison Table
| MODEL | CHANNELS | BANDWIDTH | MAX SAMPLE RATE | MEMORY | SIGNAL GENERATOR | WAVEFORM REFRESH RATE |
|---|---|---|---|---|---|---|
| MSO5072 | 2 Analogue, 16 Digital (Opt) | 70MHz | 8GSa/s | 100Mpts – Standard 200Mpts – Optional | X2 (Opt) | 500,000 wfm/s |
| MSO5074 | 4 Analogue, 16 Digital (Opt) | 70MHz | 8GSa/s | 100Mpts – Standard 200Mpts – Optional | X2 (Opt) | 500,000 wfm/s |
| MSO5102 | 2 Analogue, 16 Digital (Opt) | 100MHz | 8GSa/s | 100Mpts – Standard 200Mpts – Optional | X2 (Opt) | 500,000 wfm/s |
| MSO5104 | 4 Analogue, 16 Digital (Opt) | 100MHz | 8GSa/s | 100Mpts – Standard 200Mpts – Optional | X2 (Opt) | 500,000 wfm/s |
| MSO5204 | 4 Analogue, 16 Digital (Opt) | 200MHz | 8GSa/s | 100Mpts – Standard 200Mpts – Optional | X2 (Opt) | 500,000 wfm/s |
| MSO5354 | 4 Analogue, 16 Digital (Opt) | 350MHz | 8GSa/s | 100Mpts – Standard 200Mpts – Optional | X2 (Opt) | 500,000 wfm/s |
