优势出售原厂JST连接器11KR-6H-P图1

优势出售原厂JST连接器11KR-6H-P

2021-11-19 18:327750询价

价格:¥0.82/PCS

品牌:JST,MOLEX,JAM,AMP/TE,KET,YEONHO

加工定制:否

应用范围:电脑

起订:1000PCS

供应:29000PCS

发送询价
加工定制
应用范围 电脑
种类 插头/插座
接口类型 1394
支持卡数 单卡
读卡类型 CF
形状 条形
制作工艺 冷压
特性 阻火/阻燃
工作频率 高频
接触件材质 CU
绝缘体材质 PA
芯数 11
针数 11
线长 11(mm)
品牌 JST/压着端子
型号 11KR-6H-P

KRW connector


The KRW connector allows double-row wire-to-board connection using either the KR or PHN connectors.
*Multi-IDC-harnesses are possible.
*Various types of connectors
In addition to the KRW, KR, PHN and TR connectors, there are other 2.0mm pitch connectors available such as the KRD, CR, DA, DD and DS ranges.

Product Profile
SeriesKRW connector
CategoryWire to Board Insulation Displacement Connectors
TypeDisconnectable type
IDC style, Double-row
Specification
Pitch2.0 mm
Current rating1.0A (AWG#26)
Voltage rating100V
PC board
mounting direction
Top entry, Side entry


Compliant with RoHS.
(LF)(SN) as identification part number shall be displayed on a label.
When ordering RoHS compliant products, please inquire to the nearest
JST Sales Office, or order them with the described part number adding
(LF)(SN) as the identification marking after it.
